Best Industrial Flooring in Bangladesh​
Conductive (ESD) Flooring is a seamless epoxy or polyurethane flooring system made with conductive materials such as carbon fibers or conductive aggregates to safely control static electricity. These materials help electrical charges flow safely through grounding systems instead of building up on surfaces or people.
ESD Epoxy Flooring is a hard, durable conductive flooring system ideal for electronics factories, laboratories, and data centers with heavy traffic. ESD PU Flooring offers better flexibility, comfort, and chemical resistance, making it suitable for pharmaceutical plants, cleanrooms, and industrial facilities exposed to temperature changes and chemicals.
When people walk, move equipment, or operate machinery, static electricity builds up because of friction. Conductive ESD flooring safely directs these electrical charges through the floor into grounding points.
A complete ESD flooring system usually includes:
- Conductive primer coating.
- Copper grounding tape network.
- Conductive intermediate layer.
- Conductive or static dissipative epoxy topcoat.
- Proper grounding connection.
This system keeps static electricity under control and helps meet industrial ESD standards.
Fountech offers top-quality conductive flooring systems from certified international manufacturers. We are the authorized distributor in Bangladesh for VIACOR (Germany), which includes the reliable VIASOL UNIVERSAL VOLTEX conductive system. This system is already installed at the Bangladesh E-Passport Data Center and several multinational electronics facilities.
Our ESD flooring solutions are available in:
- Conductive Epoxy Coating Systems
- Conductive Polyurethane (PU) Flooring Systems
- Self-Leveling Conductive Floor Screeds
- Conductive Primer + Topcoat Systems
The value or positive outcomes
Fountech's conductive ESD flooring systems are engineered to meet international electrostatic discharge standards. All systems are tested and certified to comply with ANSI/ESD S20.20 and IEC 61340-5-1, the leading global frameworks for ESD protection in sensitive industrial environments.
Conductive Floor
- Electrical Resistance: 25,000 Ω – 1 MΩ
- Discharge Speed: Rapid (immediate)
- Best For: Explosive and hazardous areas
- Compressive Strength: > 60 N/mm²
- Applicable Standard: ANSI/ESD S20.20, IEC 61340-5-1
- Expected Lifespan: 10–20 years
Static Dissipative Floor
- Electrical Resistance: 1 MΩ – 1,000 MΩ
- Discharge Speed: Controlled (gradual)
- Best For: Electronics manufacturing and sensitive environments
- Compressive Strength: > 60 N/mm²
- Applicable Standard: ANSI/ESD S20.20
- Expected Lifespan: 10–20 years
Benefits of Conductive ESD Floor
- Protection of Sensitive Equipment: It prevents damage to microchips, PCBs, semiconductor devices, laboratory equipment, and automated control systems caused by electrostatic discharge.
- Improving Safety: It reduces the risk of sparks, fire hazards, and explosions in areas with flammable chemicals, solvents, or combustible materials.
- Static-Free Working Environment: It maintains controlled static dissipation for electronics manufacturing, pharmaceutical production, and cleanroom facilities.
- Durability: High-performance ESD epoxy flooring systems provide a long service life with minimal maintenance needs.
- Versatility: ESD epoxy and polyuretheane floor coatings can be applied to various flooring substrates, including concrete and tiles, making them a very highly flexible solution.
Usages Area of ESD Floor
- Electronics Manufacturing:Â ESD epoxy and PU flooring in Bangladesh is essential in electronic production facilities to prevent static damage to sensitive components.
- Laboratories:Â Research facilities use ESD floors to protect sensitive testing equipment from electrostatic interference.
- Data Centers: In environments where servers and electronic storage devices are housed . Addition the ESD PU and epoxy floor coating protects equipment from static discharge.
- Cleanrooms:Â In controlled environments like pharmaceutical or medical manufacturing. And the ESD floor paint ensures a static-free space to protect delicate products and processes.
- Chemical and Explosive Environments:Â Industries dealing with flammable substances use ESDÂ to minimize the risk of sparks that could ignite dangerous materials.
Fountech is Bangladesh’s trusted expert in industrial flooring, with a strong focus on ESD flooring. Since 2006, we have provided reliable solutions based on 18+ years of experience and over 1,300 clients.
Our certified team installs both epoxy and polyurethane ESD systems to meet international standards. We handle everything from surface preparation to grounding and topcoat application. We also offer post-installation testing and certification for complete quality assurance. We ensure long-term performance of conductive flooring.
We have successfully completed ESD flooring projects in the pharmaceutical, electronics, and chemical industries throughout Dhaka, Chittagong, Gazipur, and other industrial zones in Bangladesh.
- Surface Preparation: Clean, repair, and prepare the concrete for proper bonding.
- Primer Application: Apply conductive primer to seal and bond the surface.
- Copper Grid Installation: Lay copper strips to create a grounding network.
- Conductive Layer Application: Apply conductive or dissipative coating.
- Topcoat Finishing: Add ESD topcoat for durability and performance.
- Testing & Grounding: Test resistance and connect the system to proper grounding.
Frequently Asked Questions
What is Electrostatic Discharge (ESD) flooring?
Electrostatic Discharge (ESD) flooring is a conductive or static dissipative flooring system designed to safely control and dissipate electrostatic discharge in sensitive industrial environments.
Where is conductive ESD flooring used?
ESD flooring is commonly used in electronics factories, pharmaceutical industries, cleanrooms, laboratories, semiconductor plants, and data centers.
Can ESD flooring be installed over existing floors?
Does Fountech's ESD flooring meet international standards?
Yes. Fountech provides ESD flooring systems that meet international standards like ANSI/ESD S20.20 and IEC 61340-5-1 for safe static control. We are the authorized distributor of VIACOR Germany in Bangladesh.
Do ESD floors need a moisture barrier in Bangladesh?
Yes. Due to high humidity in Bangladesh, a moisture barrier is recommended before ESD coating to prevent blistering and delamination.
What is the difference between conductive and anti-static flooring?
Conductive flooring releases static electricity quickly, while dissipative flooring releases it more slowly and safely. The right type depends on your work environment.
How long does ESD floor coating last?
With proper preparation and professional installation, Fountech’s ESD flooring typically lasts 10–20 years in industrial use.
Is ESD epoxy flooring durable?
Yes, ESD epoxy flooring is highly durable, chemical resistant, abrasion resistant, and suitable for heavy industrial environments.
